RØDE X Streamer X Streaming Mixer

• Flexible and easy-to-use professional-quality streaming mixer
• Can be used as a video capture card, sound card and controller
• 4K30 video recording and 4K60 Pass Through through HDMI
• Revolution Preamp with Neutrik combo jack
• Built-in wireless receiver
• 4 pcs SMART pads

RØDE X Streamer X Streaming Mixer

• Flexible and easy-to-use professional-quality streaming mixer.
• Can be used as a video capture card, sound card and controller.
• Compact construction and intuitive design.
• 4K30 video recording and 4K60 Pass Through through HDMI.
• Great-sounding Revolution Preamp with Neutrik combo jack.
• Connect microphone or instrument at line level.
• 3.5 mm TRRS input for headset.
• Built-in wireless receiver so you can connect RØDE Wireless GO II and Wireless ME.
• 4 SMART pads that can be assigned to a wide range of functions.
• Can be used with RØDE software, UNIFY, RØDE Central and RØDE Connect.

• Video Input Connectors: 1 x HDMI Type A 2.0
• Video Passthrough Output: 1 x HDMI Type A 2.0
• Max Input Resolutions (HDMI In): 4Kp60 HDR, 1440p144 HDR, 1080p240 HDR
• Variable Refresh Rate Support (VRR): Yes
• Max Capture Resolutions: 4Kp30, 1440p60, 1080p120, 1080p60 HDR
• Audio Input Connectors: 1 x XLR Combo Jack (Mic/Instrument), 1 x Wireless Receiver, 1 x Input HDMI
• Audio Output Connectors: 1 x 3.5 TRRS Headset Jack (I/O), 1 x ¼" Headphone Jack
• Input Dynamic Range: 113dB
• Preamp Noise: -131.5dBV (A-weighted)
• Frequency Range: Microphone Inputs: 20Hz-20kHz, Headphone Output: 20Hz-20kHz
• Microphone Input Impedance (Ω): 4KΩ
• Instrument Input Impedance (Ω): 1MΩ
• Preamplifier Gain Range: 76dB
• Phantom Power: Yes
• Direct Monitor: Yes
• Headphone Output Power: 125mW per channel
• Internal Storage (GB): 2GB (SMART Pads)
• Power Requirements: Via USB: 5V @ 3A
• Weight (grams): 380g
• Dimensions (millimeters): Length: 144mm
• Width: 122mm
• Height: 51mm
• Included Accessories:
• 1 x Streamer X
• 1 x SC27
• 1 x Power Adapter
• RØDE Software Compatibility: RØDE Central, RØDE Unify
• USB Interface: USB 1: USB 3.1 type C, USB 2: USB 2.0 type C
• Bit Depth: 24-bit
• Sampling Rate (kHz): 48kHz
• Processing: APHEX Processing, RØDE Voice FX
• Minimum OS Requirements: macOS 10.15 or later, Windows 10 Version 1803 or later, Windows 11
